Model: GL-R550 Retro 550 LED Bar

Key Features:

Plug-and-Play AC Power:
Simply plug into any standard US outlet (100–240V) and you're ready to go. No batteries to charge, no power interruptions mid-show — just reliable, consistent output all night long.

Professional DMX512 Control with RDM:
Works seamlessly with all major DMX consoles right out of the box. The built-in RDM function lets your console communicate two-way with the fixture — no more walking to the stage to troubleshoot.

4 Channel Modes to Match Any Setup:
Whether you're running a simple 4-channel RGBW wash or a full 44-channel zone-controlled show, the GL-R550 adapts to your rig. Choose from CH04, CH13 (default), CH35, or CH44.

10 Individually Addressable RGB Zones:
Dial in precise color control across 10 separate RGB zones plus 5 white zones for eye-catching, dynamic effects that stand out at any event.

Master/Slave Sync:
Daisy-chain multiple GL-R550 bars with a standard 3-pin DMX cable. Set one as master and every other bar locks in sync instantly — perfect for DJ booths, stages, and uplighting rigs.

Ultra-Smooth 32-Bit Dimming:
Say goodbye to choppy fades. 32-bit linear dimming delivers silky-smooth 0–100% transitions on every channel, every time.

Three Powerful Built-In Effect Engines:
Color dyeing, explosion bursts, and auxiliary light effects are all built in — no laptop or extra software needed.

Benefits:

Whether you're lighting a wedding reception, corporate event, nightclub, or backyard party, the GL-R550 gives you the professional-grade output and control that mobile DJs and event lighting pros demand. Durable metal construction, flexible DMX channel options, and powerful dual-source lighting (COB + 5050 beads) means you can walk into any venue and deliver a stunning show with confidence.

Specifications:

Spec	Detail
Input Voltage	100–240V AC, 50/60Hz (US standard compatible)
Light Source	5 × 60W COB beads + 120 × RGB 5050 SMD beads
Control Modes	DMX512, Auto, Master/Slave, Sound Active
DMX Channels	CH04, CH13 (default), CH35, CH44
RDM	Yes
Dimming	32-bit, 0–100% linear (flicker-free)
Built-In Effects	Color Dyeing, Explosion, Auxiliary Light
Strobe	1–30Hz adjustable
Operating Temp	-22°F to 122°F (-30°C to 50°C)
IP Rating	IP20 (indoor use)
Housing	All-metal, black powder coat
Connections	DMX In/Out, Power In/Out
Dimensions	38.4 x 6 x 4.1 in
Weight	(Please provide)

Unit Size Imperial	Case Type	Case Sizes Imperial	Weight Imperial with Units LBS
1	Standalone Fixture	38.4 x 6 x 4.1 in
2	Box

DMX Channel Guide:

CH04 — Simple RGBW (Best for beginners or basic color mixing)

Ch	Function
1	Red
2	Green
3	Blue
4	White

CH13 — Standard Mode · Factory Default (Best for most DJ setups)

Ch	Function
1	Master Dimmer
2	RGB Strobe
3	Red
4	Green
5	Blue
6	Effect Mode
7	Effect Speed
8	Background Color
9	Background Tone
10	White Strobe
11	White
12	Effect Mode (Aux)
13	Effect Speed (Aux)

CH35 — Zone White + RGB Control (Best for pixel-style effects)

Ch	Function
1–5	White Zones 1–5
6–8	RGB Zone 1
9–11	RGB Zone 2
…	…
33–35	RGB Zone 10

CH44 — Full Zone Control + FX (Best for advanced programmers)

Ch	Function
1	Master Dimmer
2	RGB Strobe
3–32	RGB Zones 1–10 (R, G, B per zone)
33	Effect Mode
34	Effect Speed
35	Background Color
36	Background Tone
37	White Strobe
38–42	White Zones 1–5
43	Effect Mode (Aux)
44	Effect Speed (Aux)

On-Board Controls:

The GL-R550 features a simple 4-button display panel on the back for quick standalone adjustments without a DMX console.

Button	What It Does
Menu	Scroll through settings
Up ▲	Increase value
Down ▼	Decrease value
Enter/Confirm	Save your setting (remembered after power-off)

Adjustable Parameters:

DMX start address (A001–A512)
Channel mode (CH04, CH13, CH35, CH44)
Main light effect mode and speed
Auxiliary light effect mode and speed
Individual R / G / B / W brightness levels
Sound-active mode

Master/Slave Setup (No Console Needed):

Connect two or more GL-R550 bars with standard 3-pin DMX cables, daisy-chained.
Set one fixture as Master — this unit controls the show.
All other fixtures automatically become Slaves and mirror the master in real time.
Works for gradients, pulses, color jumps, sound-active, and auto-run effects.

⚠️ Important: Only set ONE fixture as master per chain. Multiple masters will cause all fixtures to flash out of sync.

Package Includes:

1x Retro 550 Fixture

1x Powercon Power Cable
1x DMX Cable

1x User Manual

Manual & Guides:

User Manual
